Description
Fast Switching Surface Mount Diode.
Features
● Fast Switching Speed
● Surface Mount Package Ideally Suited for Automatic Insertion
● General Purpose Rectification
● Silicon Epitaxial Planar Construction
Applications
● This product is general usage and suitable for many different applications.
● Extreme fast switches.
Mechanical Data
● Case: LL-34
● Polarity: Cathode Band
● Marking: Cathode Band Only
● Weight: 0.12 grams (approx.)
Quick reference data
Symbol | Parameter | Conditions | Max | Unit |
IR | reverse current | Tamb = 25 °C | 5 | μA |
VR | reverse voltage | 75 | V | |
trr | reverse recovery time | IF=10mA to IR=1mA. VR=6.0V,RL=100Ω | 4 |
ns |
