Features
● IEC 61000-4-2±15Vcontact±15kVair
● IEC 61000-4-4(EFT)40A(5/50ns)
● IEC 61000-4-5(Lightning)3.5A(8/20μs)
● 60Watts peak pulse power(tp=8/20μs)
● Solid-statesilicon-avalanche technology
● Protection two datalines
● Low clamping voltage
● Low leakage current
● Low Low capacitance(Cj=0.7pFtyp.)
● Bidirectional and unidirectional configurations
Mechanical Data
● SOT-23 package
● Flammability Rating: UL 94V-0
● Packaging: Tape and Reel
● RoHS/WEEE Compliant
Applications
● Dataline
● Automatic Teller Machines
● Networks
● Powerline
Name
Title
Description
Datasheet
Support
Support
If you need design/technical support, please let us know and fill inResponse FormWe will get back to you as soon as possible.
Longevity
The Longevity Program is aimed to provide our customers information from time to time about the expected time that our products can be ordered. The NLP is reviewed and updated regularly by our executive Management Team. View ourlongevity programhere.
5.0SMDJ18A TVS Diode SMC
Brand: slkor， VRWM(V)： 18V VBR min(V)： 20V VBR max(V)： 22.1V IR(uA)： 1μA VC(V)： 29.2V Package： SMC
5.0SMDJ28A TVS Diode SMC
Brand: slkor， VRWM(V)： 28V VBR min(V)： 31.1V VBR max(V)： 34.4V IR(uA)： 1μA VC(V)： 45.4V Package： SMC
5.0SMDJ30CA TVS Diode SMC
Brand: slkor， VRWM(V)： 30V VBR min(V)： 33.3V VBR max(V)： 36.8V IR(uA)： 1μA VC(V)： 48.4V Package： SMC
5.0SMDJ33A TVS Diode SMC
Brand: slkor， VRWM(V)： 33V VBR min(V)： 36.7V VBR max(V)： 40.6V IR(uA)： 1μA VC(V)： 53.3V Package： SMC
5.0SMDJ33CA TVS Diode SMC
Brand: slkor， VRWM(V)： 33V VBR min(V)： 36.7V VBR max(V)： 40.6V IR(uA)： 1μA VC(V)： 53.3V Package： SMC
5.0SMDJ36CA TVS Diode SMC
Brand: slkor， VRWM(V)： 36V VBR min(V)： 40V VBR max(V)： 44.2V IR(uA)： 1μA VC(V)： 58.1V Package： SMC
5.0SMDJ43CA TVS Diode SMC
Brand: slkor， VRWM(V)： 43.0 V VBR min(V)： 47.80 V VBR max(V)： 52.80 V IR(uA)： 1μA VC(V)： 69.4 V Package： SMC
5.0SMDJ58A TVS Diode SMC
Brand: slkor， VRWM(V)： 58V VBR min(V)： 64.4V VBR max(V)： 71.2V IR(uA)： 1μA VC(V)： 93.6V Package： SMC
5.0SMDJ58CA TVS Diode SMC
Brand: slkor， VRWM(V)： 58V VBR min(V)： 64.4V VBR max(V)： 71.2V IR(uA)： 1μA VC(V)： 93.6V Package： SMC
5.0SMDJ64CA TVS Diode SMC
Brand: slkor， VRWM(V)： 64V VBR min(V)： 71.1V VBR max(V)： 78.6V IR(uA)： 1μA VC(V)： 103.0 V Package： SMC
